Input Signals

DVI

Connector

DVI-D

Signal Support

DVI 1.0 format standard and HDCP compliant

Video Support

Up to 720P/960P/1080p@60Hz, 4K*2K@60Hz

Audio Support

Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6.1, DTSHD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)

Chroma Subsampling

Max 3840*2160@60Hz (4:2:0)

Max 3840*2160@30Hz (4:4:4, 4:2:2)

EDID

Bi-Directional (Forward + Backward) Transmission:

Support Dynamic EDID, Plug & Play, no need to learn

Single-Directional (Forward) Transmission:

Support EDID learning manually

Audio Interface

3.5MM external stereo audio

Fiber Connector

SFP/LC

Bandwidth

10.2Gbps

Transmission Distance

300m (Over OM3 Fiber)

Up to 80km (Over Single-mode Fiber)

Operating Temperature

-10 ~ + 50°C

Storage Temperature

-20 ~ + 80°C

Humidity

5% to 90% RH (non-condensing)

MTBF

100,000 hours

Dimension (WxDxH)

2.87 x 1.73 x 0.69in (73x44x17mm)

Weight

60g / 0.13 lb

Power Supply

5V DC (USB-C)

Power dissipation

<5W

Safety Approvals

CE, FCC, Rohs
